0.1-1.5 In Lbs Tohnichi Torque Gauge - 1.5BTG-A-S

0.1-1.5 In Lbs Tohnichi ATG / BTG Torque Gauge - 1.5BTG-A-S

Features

• Torque gauge series designed to measure low torque from 0.5mN • m to 150cN • m
• Two Body Sizes: ATG smaller and BTG larger coordinate with torque ranges.
• Bi-directional operation handheld type torque gauge.
• Aluminum Threaded keyless 3-jaw chuck is standard. (order replacement #00T45502B for ATG & #00T04282A for BTG)
• For ATG: plastic chuck #322 or steel chuck #321 are also available as optional accessories
• Push lock button holds the gauge in place while securing test object in the chuck
• The dial is scaled by 270 degrees with a stopper which prevents over-loading.
• Includes plastic storage case and certificate of calibration
• For calibration, use calibration kits ATGTCL for ATG, and BTGTCL for BTG (sold separately) or contact our repair dept.
• Top and Side scales feature memory pointers to insure easy and accurate torque reading from different angles.

Specifications

Made In Japan
