8,000 Ft Lbs 1 1/2" Dr Williams 4.6:1 Torque Multiplier - TM-2000

The Williams TM-2000 Torque Multiplier with Handle offers a torque ratio of 4.6:1 and a maximum output of 8,000 Ft Lbs or 10,846 Nm.

4.6 to 1 Torque Multiplier Features:

• The Williams TM-2000 Torque Multiplier provides the operator with nut-turning power that requires only a fraction of the force required when using conventional tools.
• Input and output rotation is in the same direction.
• Reaction bar rotation is opposite to input direction and must rest securely against a rigid object to withstand the generated reaction force.
• By removing 4 screws, heads may be easily disassembled for inspection, cleaning and lubrication.
• Max Output Ft. Lbs.: 8000
• Multiplication Ratio: 4.6 to 1
• Approx Ft Lbs for Max Output: 1915
• Input Female Sq.: 1
• Output Male Sq.: 1 1/2"
• Head Thickness Inc. Tang: 6 1/4
• Head Dia.: 6 1/2
• Oal. Lgth. Inc. Reaction Bar: 31
