3/8'' Williams 5T Pull Cylinder - 6CP05T05

The 6CP05T05 3/8'' Williams 5T Pull Cylinder - 6CP05T05 comes with the Williams Industrial Brands Limited lifetime warranty.

5T Pull Cylinder

Features

• High strength steel construction
• High strength steel construction
• One piece high grade alloy bearing for side load protection and longer life
• Polyurethane cup seal helps provide optimum performance
• External plunger threads
• Internal base threads
• Used for pulling and tensioning
• Maximum working pressure : 10,000 psi / 700 bar
• Country of Origin : Taiwan
• Cylinder Capacity (tons) : 5
• Stroke (in) : 5.55
• Cylinder Effective Area (in2) : 1.14
• Pressure at capacity (psi) : 8,770
• Oil Capacity (in3) : 6.34
• Collapsed Height A (in) : 11.85
• Extended Height B (in) : 17.35
• Outside Dia. D (in) : 2.25
• Cylinder Bore Dia. C (in) : 1.69
• Top to Inlet Port G (in) : 1.50
• Collar Thread H (in) : 2 1/4"-14
• Collar Thread Length L (in) : 1
• Adapter Thread F (in) : 1 1/4"-11.5NPTF
• Adapter Length P (in) : 1.25
• Plunger Dia. E (in) : 1.18
• Plunger Thread Length K (in) : 0.93
• Plunger Thread Q (MM) : M28x1.5
• Base Mounting Hole Thread H : 1 1/4"-11.5NPTF
• Base Mounting Hole Thread Z (in) : 0.95
